1.5SMC400A 400A 的参数 |
| 极性
Polarization |
单向 Unidirectional |
| 反向关断电压/工作电压VRWM
Reverse Standoff Voltage |
342V |
| 反向击穿电压VBR
Breakdown Voltage |
400V |
| 峰值脉冲耗散功率PPPM
Peak Pulse Power Dissipation |
1500W |
| 峰值脉冲电流IPPm
Peak Forward Surge Current |
2.8A |
| 额定耗散功率Pd
Power dissipation |
|
| Description & Applications |
Transient Voltage Suppression Diodes；Features ? RoHS compliant ? For surface mounted applications in order to optimize board space ? Low profile package ? Built-in strain relief ? Glass passivated junction ? Low Inductance ? Excellent clamping capability ? Repetition Rate (duty cycle):0.05% ? Fast response time: typically less than 1.0ps from 0 Volts to BV min. ? Typical IR less than 1μA above 10V ? High temperature soldering: 250?C/10 seconds at terminals |
| 描述与应用 |
瞬态电压抑制二极管;特性 ?通过无铅认证 ?表面安装的应用程序为了优化板空间 ?低轮廓包 ?内置应变张拉 ?玻璃钝化结 ?低电感 ?优秀的夹紧能力 ?重复率(周期性):0.05% ?快速响应时间:通常小于1.0 ps从0伏来 BV min。 ?典型红外小于1μa高于10 v ?高温钎焊:250?C / 10秒在终端 |
