2SD1033-E1 D1033 的参数 |
| 集电极-基极反向击穿电压V(BR)CBO
Collector-Base Voltage(VCBO) |
200V |
| 集电极-发射极反向击穿电压V(BR)CEO
Collector-Emitter Voltage(VCEO) |
150V |
| 集电极连续输出电流IC
Collector Current(IC) |
2A |
| 截止频率fT
Transtion Frequency(fT) |
10MHz |
| 直流电流增益hFE
DC Current Gain(hFE) |
40~200 |
| 管压降VCE（sat）
Collector-Emitter Saturation Voltage |
200mV/0.2V |
| 耗散功率Pc
Power Dissipation |
2W |
| Description & Applications |
Silicon NPN epitaxial transistors description 2SD1033 is designed for color TV Vertical deflection output especially in hybrid integrated circuits Features * high voltage Vceo=150V |
| 描述与应用 |
NPN硅外延晶体管 描述 2SD1033是专为彩电垂直偏转输出 特别是在混合集成电路 ?特点 *高电压VCEO=150V |
