TC75S101FU SJ 的参数 |
| 电路数
Number of Circuits |
1 |
| 转换速率
Slew Rate |
0.15V/μs |
| 增益带宽积
Gain Bandwidth Product |
0.62MHz |
| 共模抑制比
Common Mode Rejection Ratio |
66dB |
| -3db 带宽
-3db Bandwidth |
|
| 输入偏置电流
Current - Input Bias |
0.1pA |
| 输入失调电压
Voltage - Input Offset |
1.2mV |
| 电源电流
Current - Supply |
57μA |
| 电流 - 输出/通道
Current - Output / Channel |
1.5mA |
| 电压 - 电源，单/双 (±)
Voltage - Supply, Single/Dual (±) |
1.5V ~ 5.5V |
| Description & Applications |
Single Operational Amplifier (Input and Output Full Range);· Low-input offset voltage · Low-input bias current · Built-in phase-compensated op-amp, obviating the need for any external device · Ultra-small package |
| 描述与应用 |
单运算放大器(输入和输出全系列);·低输入失调电压 ·低输入偏置电流 ·内置相位补偿运算放大器，省却任何外部设备 ·采用超小型封装 |
