CR05AS-8-ET14 CD 的参数 |
| 反向重复峰值电压VRRM/断态重复峰值电压VDRM
Repetitive peak reverse voltage/Repetitive peak off-state voltage |
400V |
| 通态平均电流IT(AV)
Average on-state current |
0.5A |
| 通态最大电流IT(RMS)
RMS on-state current |
0.79A |
| 栅极触发电压VGT
Gate trigger voltage |
0.8V |
| 栅极触发电流IGT
Gate trigger current |
1μA-100μA |
| 保持电流IH
Holding current |
3mA |
| 峰值通态电压VTM
On-state voltage |
1.9V |
| 重复峰值断态电流IDRM
Repetitive peak off-state current |
0.1mA |
| 浪涌电流ITSM(50Hz、60Hz)
Current - Non Rep. Surge 50, 60Hz (Itsm) |
10A |
| Description & Applications |
Low Power Use For Solid state relay, strobe flasher, igniter, and hybrid IC Non-Insulated Type Planar Passivation Type |
| 描述与应用 |
低功耗使用 用于固态继电器，频闪闪光器，点火器和混合集成电路 非绝缘型 平面钝化类型 |
| 技术文档PDF下载 |
在线阅读  |
|
|
|
|
|
相关型号列表 |
| 型号 |
标记/丝印/代码 |
厂家 |
批号 |
封装 |
数量 |
描述 |
详细资料 |
| CR05AS-8-B |
CD |
MITSUBISHI |
05+ |
SOT-89 |
50 |
可控硅/晶闸管Triac/Thyristor,SCR-单向可控硅Thyristor,SCR |
查看 |
| CR05AS-8-B |
CD |
MITSUBISHI |
05+ |
SOT-89 |
0 |
可控硅/晶闸管Triac/Thyristor,SCR-单向可控硅Thyristor,SCR |
查看 |
| CR05AS-8-CT13 |
CD |
RENESAS |
06NOPB |
SOT-89 |
0 |
可控硅/晶闸管Triac/Thyristor,SCR-单向可控硅Thyristor,SCR |
查看 |
| CR05AS-8-ET14 |
CD |
RENESAS |
10NOPB10+ROHS |
SOT-89 |
0 |
可控硅/晶闸管Triac/Thyristor,SCR-单向可控硅Thyristor,SCR |
查看 |
| CR05AS-8-C |
CD |
RENESAS |
05+ |
SOT-89 |
2600 |
可控硅/晶闸管Triac/Thyristor,SCR-单向可控硅Thyristor,SCR |
查看 |
| CR05AS-8-A |
CD |
RENESAS |
05+ |
SOT-89 |
0 |
可控硅/晶闸管Triac/Thyristor,SCR-单向可控硅Thyristor,SCR |
查看 |
| CR05AS-8-A |
CD |
RENESAS |
06+ROHS |
SOT-89 |
0 |
可控硅/晶闸管Triac/Thyristor,SCR-单向可控硅Thyristor,SCR |
查看 |
| CR05AS-8-A |
CD |
RENESAS |
06+ROHS |
SOT-89 |
0 |
可控硅/晶闸管Triac/Thyristor,SCR-其它Other |
查看 |
| CR05AS-8-ET14 |
CD |
RENESAS |
10+ROHS |
SOT-89 |
0 |
可控硅/晶闸管Triac/Thyristor,SCR |
查看 |
|
|
|
