型号: |
CCR48.OMS6T |
标记/丝印/代码/打字: |
|
厂家: |
TDK |
封装: |
4532 |
批号: |
05+ |
库存数量: |
1000 |
所属分类: |
晶振滤波Crystal Oscillator and Filter 晶振Crystal Oscillator 谐振器Resonator |
技术文档PDF: |
在线阅读 ![](images/pdf.jpg) |
|
|
在线购买 |
|
|
|
|
CCR48.OMS6T 的参数 |
类型
Type |
Ceramic |
谐振频率
Frequency |
48MHz |
频率容差
Frequency Tolerance |
±0.5% |
频率稳定性
Frequency Stability |
±0.2% |
负载电容
Load Capacitance |
8pF |
谐振阻抗
Resonant impedance |
40? |
Description & Applications |
FEATURES ? CCR(Built-in load capacity/External load capacity) series ? The CCR series are thin-type ceramic chip resonators. Thickness shear mode or 3rd over-tone thickness expansion mode element are used for both the 4.0 to 11.0MHz band and the 16.0 to 50.0MHz band. ? Products with built-in loading capacitance have piezoelectric elements that are mounted onto a capacity-forming dielectric substrate.This eliminates the need for external capacitors, thus simplifying circuit requirements. ? Optimization of the temperature characteristics of both the piezoelectric element and dielectric materials has resulted in stable oscillating frequency. ? Corresponds to reflow soldering. Moreover, it is possible to correspond Pb-free soldering.(260°C,10sec. max.) Packaging style is emboss taping. ? Setting or matching of oscillating frequency which correspond to new models, application IC or custom IC are also available, |
描述与应用 |
特点 ?CCR(内置负载容量/外部负载能力)系列 ?CCR一系列超薄型陶瓷片谐振器。厚度剪切模式或第三过音的厚度扩展模式元件用于同时为4.0至11.0MHz频带和16.0到50.0MHz的频带。 产品具有内置的负载电容,到一个能力形成的电介质基板上安装有压电元件。这消除了需要外部电容,从而简化了电路的要求。 ?在压电元件和电介质材料的温度特性的优化,导致在稳定的振荡频率。 ?对应回流焊接。此外,它可以对应无铅焊接(260℃,10秒以下)包装风格浮雕录音。 ?设置或应用IC振荡频率对应新车型的匹配,或定制IC都还可以, |
技术文档PDF下载 |
在线阅读 ![](images/pdf.jpg) |
|
|
|
|
