TF246-5-TL-H F 的参数 |
| 最大源漏极电压Vds
Drain-Source Voltage |
20v |
| 栅源极击穿电压V(BR)GS
Gate-Source Voltage |
-20v |
| 漏极电流(Vgs=0V)IDSS
Drain Current |
0.21~0.35ma |
| 关断电压Vgs(off)
Gate-Source Cut-off Voltage |
-0.2~-1v |
| 耗散功率Pd
Power Dissipation |
30mw |
| Description & Applications |
N-channel Silicon Junction FET ?Electret Condenser Microphone Applications ?Especially suited for use in electret condenser microphone. ? Excellent voltage characteristics. ? Excellent transient characteristics. |
| 描述与应用 |
N沟道硅结型场效应管 ?驻极体电容式麦克风的应用 ?尤其适用于使用在驻极体电容传声器。 ?优秀的电压特性。 ?出色的瞬态特性。 |
