RT9161-15PX AP 的参数 |
| 电路数量
Number of Regulators |
1 |
| 输入电压VIN
Voltage - Input |
-0.3~14V |
| 输出电压VOUT
Voltage - Output |
1.5V |
| 输出电流Io
Current - Output |
300mA/0.3A |
| 最大压降VDO
Voltage - Dropout |
450mV/0.45V |
| 带使能脚EN/CE(ON/OFF功能)
With Enable Pin |
无 No |
| 最大耗散功率Pd
Power dissipation |
500mW/0.5W |
| Description & Applications |
300/500mA Low Dropout Linear Voltage Regulator ;?Low Dropout Voltage of 200mV at Output ?Current 100mA, 450mV at Output Current ?Guaranteed 300/500mA Output Current ? Low Ground Current 110 A ? 2% Accuracy Output Voltage ? Input Voltage Range up to 12V ? Extremely Tight Load Regulation ? Fast Transient Response ?Current-limiting and Thermal-limiting |
| 描述与应用 |
300/500mA低压差线性稳压器;?200mV的低压差输出 ?电流100mA，450mV的输出电流 ?保证300/500mA输出电流 ?低接地电流110 A ?2％的输出电压精度 ?输入电压范围高达12V ?极其严格的负载调整 ?快速瞬态响应 ?电流限制和热限制 |
