MIC5305-2.85BML
 型号:  MIC5305-2.85BML
 标记/丝印/代码/打字:  N82
 厂家:  MICREL
 封装:  MLF22-06L/6MLF 2X2
 批号:  05+
 库存数量:  41239
 所属分类:  电源管理ICPower Management IC/PMIC
  电压调整器/稳压Voltage Regulator
    低压差LDOLow Dropout (LDO)
 技术文档PDF:  在线阅读

 在线购买

MIC5305-2.85BML N82 的参数

电路数量 Number of Regulators 1
输入电压VIN Voltage - Input 2.25~5.5V
输出电压VOUT Voltage - Output 2.85V
输出电流Io Current - Output 150mA/0.15A
最大压降VDO Voltage - Dropout 85mV
带使能脚EN/CE(ON/OFF功能) With Enable Pin 无 No
最大耗散功率Pd Power dissipation
Description & Applications 150mA μCap Ultra-Low Dropout LDO Regulator ;?Ultra-low dropout voltage of 60mV @ 150mA ? Input voltage range: 2.25 to 5.5V ? Stable with ceramic output capacitor ? 150mA guaranteed output current ? Low output noise — 20μVrms ? Low quiescent current of 90μA total ? High PSRR, up to 85dB @1kHz ? Less than 30μs turn-on time w/CBYP = 0.01μF ? High output accuracy: – ±1.0% initial accuracy – ±2.0% over temperature ? Thermal shutdown protection ? Current limit protection ? Cellular phones ? PDAs ? Fiber optic modules ? Portable electronics ? Notebook PCs ? Audio Codec power supplies
描述与应用 150MAμCap超低压差 LDO稳压器;?超低压降电压60mV的@150MA ?输入电压范围:2.25至5.5V ?与陶瓷输出电容稳定 ?保证150mA输出电流 ?低输出噪声 - 20μVRMS ?总90μA的低静态电流 ?高PSRR,到85分贝@1KHZ ?小于30μs的导通时间瓦特/ CBYP=0.01μF ?高输出精度: - ±1.0%的初始精度 - 温度的±2.0% ?热关断保护 ?电流限制保护 ?蜂窝电话 ?掌上电脑 ?光纤模块 ?便携式电子产品 ?笔记本电脑 ?音频编解码器电源
技术文档PDF下载 在线阅读



 相关型号列表

型号 标记/丝印/代码 厂家 批号 封装 数量 描述 详细资料
MIC5305-2.5BD5 N825 MICREL 06+ SOT-153/SOT23-5 6000 电源管理ICPower Management IC/PMIC-电压调整器/稳压Voltage Regulator-低压差LDOLow Dropout (LDO) 查看
MIC5305-2.5YD5 N825 MICREL 06+NOPB SOT-153/SOT23-5 1416 电源管理ICPower Management IC/PMIC-电压调整器/稳压Voltage Regulator-低压差LDOLow Dropout (LDO) 查看
MIC5305-2.8YML B28 MICREL 06NOPB MLF22-06L/6MLF 2X2 1888 电源管理ICPower Management IC/PMIC-电压调整器/稳压Voltage Regulator-低压差LDOLow Dropout (LDO) 查看
MIC5305-2.9BML B29 MICREL 06+ MLF22-06L/6MLF 2X2 1239 电源管理ICPower Management IC/PMIC-电压调整器/稳压Voltage Regulator-低压差LDOLow Dropout (LDO) 查看
MIC5305-2.9YML Y29 MICREL 06NOPB MLF22-06L/6MLF 2X2 150000 电源管理ICPower Management IC/PMIC-电压调整器/稳压Voltage Regulator-低压差LDOLow Dropout (LDO) 查看
MIC5305-2.85BML N82 MICREL 05+ MLF22-06L/6MLF 2X2 41239 电源管理ICPower Management IC/PMIC-电压调整器/稳压Voltage Regulator-低压差LDOLow Dropout (LDO) 查看
MIC5305-2.6YML 826 MICREL 05NOPB mlf22D-06L/6MLF 2X2 0 电源管理ICPower Management IC/PMIC-电压调整器/稳压Voltage Regulator-低压差LDOLow Dropout (LDO) 查看
MIC5305-2.85BML N82 MICREL 0548+ MLF22-06L/6MLF 2X2 0 电源管理ICPower Management IC/PMIC-电压调整器/稳压Voltage Regulator-低压差LDOLow Dropout (LDO) 查看
