型号： |
UGN3175LT |
| 标记/丝印/代码/打字： |
N3175 |
| 厂家： |
jat |
| 封装： |
SOT-89 |
| 批号： |
01+ |
| 库存数量： |
300 |
| 所属分类： |
集成电路ICIntegrated Circuit（IC）
霍尔ICHALL IC |
| 技术文档PDF： |
在线阅读  |
| |
|
| 在线购买 |
|
|
|
|
UGN3175LT N3175 的参数 |
| 感应范围
Sensing Range |
50/150G跳闸,-150/-50G释放 50/150G Trip,-150/-50G Release |
| 类型
Type |
霍尔效应开关 Hall Effect Switch |
| 电源电压
Voltage - Supply |
4.5-18V |
| 电源电流
Current - Supply |
10mA |
| 输出电流
Current - Output (Max) |
5μA |
| Description & Applications |
HALL-EFFECT LATCHES These Hall-effect latches are temperature-stable and stress-resistant sensors especially suited for electronic commutation in brushless dc motors using multipole ring magnets. Each device includes a voltage regulator, quadratic Hall voltage generator, temperature compensation circuit, signal amplifier, Schmitt trigger, and an open-collector output on a single silicon chip. The on-board regulator permits operation with supply voltages of 4.5 volts to 18 volts. The switch output can sink 10 mA. With suitable output pull up, they can be used directly with bipolar or MOS logic circuits. The three package styles available provide a magnetically optimizedpackage for most applications. Suffix ‘LT’ is a surface-mount SOT-89/ TO-243AA package; suffixes ‘U’ and ‘UA’ feature wire leads for hrough-hole mounting. FEATURES Symmetrical Response 4.5 V to 18 V Operation Open-Collector Output Reverse Battery Protection Activate With Small, Commercially Available Permanent Magnets Solid-State Reliability Small Size Superior Temperature Stability Resistant to Physical Stress |
| 描述与应用 |
霍尔效应锁存 这些霍尔效应锁存器的温度稳定性和耐应力 传感器特别适合于电子换向无刷直流电 电机采用多极环形磁铁。每个装置包括一个电压 二次稳压器，霍尔电压发生器，温度补偿 电路，信号放大器，施密特触发器和集电极开路输出 一个单一的硅芯片。板上稳压器允许操作电源电压为4.5伏到18伏。开关量输出，可以吸收10日均线。 用合适的输出上拉，就可以直接使用与双极或MOS逻辑电路。三种封装样式提供磁性优化 对于大多数应用程序包。后缀LT是一个表面贴装SOT-89/O-243AA封装后缀U，UA功能引线为hrough孔安装。 对称响应 4.5 V至18 V工作 集电极开路输出 反向电池保护 具有体积小，市售的永久磁铁激活 固态可靠性 小型 卓越的温度稳定性 抗物理应力 |
