TC7WBL125FK
 型号:  TC7WBL125FK
 标记/丝印/代码/打字:  BL125
 厂家:  TOSHIBA
 封装:  VFSOP8/US8
 批号:  05+
 库存数量:  3400
 所属分类:  集成电路ICIntegrated Circuit(IC)
  逻辑电路Logic circuit
    解码器、多路复用器、信号开关Signal Switch, Multiplexer, Decoder
 技术文档PDF:  在线阅读

 在线购买

TC7WBL125FK BL125 的参数

类型 Type 总线开关 Bus Switch
电路 Circuit
独立电路 Independent Circuits
输出高,低电流 Current - Output High, Low
单电源 Voltage Supply Source 单电源 Single Supply
电源电压 Voltage - Supply 2 V ~ 3.6 V
Description & Applications The TC7WBL126FK is a low on-resistance, high-speed CMOS 2-bit bus switch with low voltage operation. This bus switch allows the connections or disconnections to be made with minimal propagation delay while maintaining Low power dissipation which is the feature of CMOS. When output enable (OE) is at High level, the switch is on; when at Low level, the switch is off. P-MOS and N-MOS channel block also allows that the device is suitable for analog signal transmission. All inputs are equipped with protection circuits to protect the device from static discharge. Operating voltage: VCC = 2~3.6 V High speed operation: tpd = 0.25 ns (max) @3 V Ultra-low on resistance: RON = 5 ? (typ.) @3 V Electro-static discharge (ESD) performance: ±200 V or more (JEITA) ±2000 V or more (MIL) High noise immunity: VNIH = VNIL = 28% VCC (min) Power-down protection for inputs and I/O terminals. Package: US8
描述与应用 TC7WBL126FK是一个低导通电阻,高速CMOS 2位总线开关,低电压操作。这个总线开关允许以最小的传播延迟连接或断开,同时保持CMOS低功耗的特点。当输出使能(OE)为高电平时,开关处于打开状态。为低电平时,开关处于关闭状态。P-MOS和N-MOS通道块允许该设备适合于模拟信号的传输。所有输入都配有保护电路以保护设备免受静电放电。 工作电压:VCC= 2?3.6 V 高速运行:TPD= 0.25NS(最大值)@3 V 超低导通电阻RON= 5Ω(典型值),3 V 静电放电(ESD)性能:±200 V或以上(JEITA)±2000 V以上(MIL) 高抗干扰性:VNIH= VNIL=28%VCC(分钟) 断电保护的输入和I/O端子。 包装:US8
技术文档PDF下载 在线阅读



 相关型号列表

型号 标记/丝印/代码 厂家 批号 封装 数量 描述 详细资料
TC7WBL125AFK WLA125 TOSHIBA 06+PB VFSOP8/US8 50 集成电路ICIntegrated Circuit(IC)-逻辑电路Logic circuit-解码器、多路复用器、信号开关Signal Switch, Multiplexer, Decoder 查看
TC7WBL125FK BL125 TOSHIBA 05+ VFSOP8/US8 3400 集成电路ICIntegrated Circuit(IC)-逻辑电路Logic circuit-解码器、多路复用器、信号开关Signal Switch, Multiplexer, Decoder 查看
TC7WBL126FK TOSHIBA 05+ VFSOP8/US8 5500 集成电路ICIntegrated Circuit(IC)-逻辑电路Logic circuit-解码器、多路复用器、信号开关Signal Switch, Multiplexer, Decoder 查看
TC7WBL126AFK WBL126 TOSHIBA 11+ROHS VFSOP8/US8 38000 集成电路ICIntegrated Circuit(IC)-逻辑电路Logic circuit-解码器、多路复用器、信号开关Signal Switch, Multiplexer, Decoder 查看
TC7WBL126AFK WLA126 TOSHIBA 12+ROHS VFSOP8/US8 0 集成电路ICIntegrated Circuit(IC) 查看
