型号： |
TC7WB126FK |
| 标记/丝印/代码/打字： |
WB126 |
| 厂家： |
TOSHIBA |
| 封装： |
VFSOP8/US8 |
| 批号： |
13+ROHS |
| 库存数量： |
158500 |
| 所属分类： |
集成电路ICIntegrated Circuit（IC）
逻辑电路Logic circuit
解码器、多路复用器、信号开关Signal Switch, Multiplexer, Decoder |
| 技术文档PDF： |
在线阅读  |
| |
|
| 在线购买 |
|
|
|
|
TC7WB126FK WB126 的参数 |
| 类型
Type |
总线开关 Bus Switch |
| 电路
Circuit |
1 x 1:1 |
| 独立电路
Independent Circuits |
2 |
| 输出高，低电流
Current - Output High, Low |
|
| 单电源
Voltage Supply Source |
单电源 Single Supply |
| 电源电压
Voltage - Supply |
4.5 V ~ 5.5 V |
| Description & Applications |
The TC7WB126FK is a low on-resistance, high-speed CMOS dual-bit bus switch. This bus switch allows the connections or disconnections to be made with minimal propagation delay while maintaining Low power dissipation which is the feature of CMOS. When output enable (OE) is at High level, the switch is on; when at Low level, the switch is off. All inputs are equipped with protector circuits to protect the device from static discharge. Operating voltage: VCC = 4.5~5.5 V High speed operation: tpd = 0.25 ns (max) Ultra-low on resistance: RON = 5 ? (typ.) Electro-static discharge (ESD) performance: ±200 V or more (JEITA) ±2000 V or more (MIL) TTL level input (control input) Package: US8 |
| 描述与应用 |
TC7WB126FK是一个低导通电阻，高速CMOS双位总线开关。这个总线开关允许以最小的传播延迟连接或断开，同时保持CMOS低功耗的特点。当输出使能（OE）为高电平时，开关处于打开状态。为低电平时，开关处于关闭状态。所有输入都配有保护电路的静电放电保护装置。 工作电压：VCC= 4.5?5.5 V 高速运行：TPD =0.25 ns（最大） 超低电阻：RON= 5Ω（典型值） 静电放电（ESD）性能：±200 V或以上（JEITA）±2000 V以上（MIL） TTL电平输入（控制输入） 包装：US8 |
