SN74LVC1G32DBVR C32 的参数 |
| 逻辑类型
Logic Type |
或门 OR Gate |
| 电路数
Number of Circuits |
1 |
| 输入数
Number of Inputs |
2 |
| 电源电压Vcc
Voltage - Supply |
1.65V~5.5V |
| 静态电流Iq
Current - Quiescent (Max) |
10μA |
| 输出高，低电平电流
Current - Output High, Low |
-32mA,32mA |
| 低逻辑电平
Logic Level - Low |
0.7 V ~ 0.8 V |
| 高逻辑电平
Logic Level - High |
1.7 V ~ 2 V |
| 传播延迟时间@Vcc，CL
Max Propagation Delay @ V, Max CL |
4nS @5v,50pF |
| Description & Applications |
SINGLE 2-INPUT POSITIVE-OR GATE ；? Available in the Texas Instruments NanoFree? ? Latch-Up Performance Exceeds 100 mA Per Package JESD 78, Class II ? Supports 5-V VCC Operation ? Inputs Accept Voltages to 5.5 V ? Max tpd of 3.6 ns at 3.3 V ? Low Power Consumption, 10-μA Max ICC ? ±24-mA Output Drive at 3.3 V ? Ioff Supports Partial-Power-Down Mode Operation ? ESD Protection Exceeds JESD22 – 2000-V Human-Body Model (A114-A) – 1000-V Charged-Device Model (C101) |
| 描述与应用 |
单2输入正或门;?可在德州仪器NanoFree? ?闭锁性能超过100 mA每 包装JESD 78，II类 ?支持5-V VCC操作 ?接受输入电压为5.5 V ?最大TPD为3.6 ns在3.3 V ?低功耗，10μA最大ICC ?±24 mA输出驱动在3.3 V ?IOFF支持部分掉电模式操作 ?ESD保护超过JESD22 - 2000-V人体模型（A114-A） - 1000-V带电器件模型（C101） |
| 技术文档PDF下载 |
在线阅读  |
|
|
|
|
|
相关型号列表 |
| 型号 |
标记/丝印/代码 |
厂家 |
批号 |
封装 |
数量 |
描述 |
详细资料 |
| SN74LVC1G32DBVR |
C32 |
TEXAS |
05+ |
SOT-153/SOT23-5/SC-74A |
3013 |
集成电路ICIntegrated Circuit（IC）-逻辑电路Logic circuit-逻辑门Gate |
查看 |
| SN74LVC1G32DBVR |
C32 |
TEXAS |
05+ |
SOT-153/SOT23-5/SC-74A |
0 |
集成电路ICIntegrated Circuit（IC）-逻辑电路Logic circuit-逻辑门Gate |
查看 |
| SN74LVC1G32DCK3 |
CGZ |
TEXAS |
05+ |
SOT-353/SC70-5/SC-88A |
73 |
集成电路ICIntegrated Circuit（IC）-逻辑电路Logic circuit-逻辑门Gate |
查看 |
| SN74LVC1G32DCKR |
CGR |
TEXAS |
05+NOPB |
SOT-353/SC70-5/SC-88A |
806 |
集成电路ICIntegrated Circuit（IC）-逻辑电路Logic circuit-逻辑门Gate |
查看 |
| SN74LVC1G32YZPR |
E3 |
TEXAS |
05+NOPB |
5-DSBGA/5-WCSP |
0 |
集成电路ICIntegrated Circuit（IC）-逻辑电路Logic circuit-逻辑门Gate |
查看 |
|
|
|
