| Description & Applications |
STEP-UP, PWM CONTROL or PWM / PFM SWITCHABLE BUILT-IN TRANSISTOR SWITCHING REGULATOR ? Low voltage operation: Startup at 0.9 V min. (IOUT = 1 mA) guaranteed ? Low current consumption : During operation 18.7 μA (3.3 V, 50 kHz, typ.) During shutdown: 0.5 μA (max.) ? Duty ratio : Built-in PWM switching control circuit (S-8354 Series) 15 % to 83 % (30 kHz and 50 kHz models) 15 % to 78 % (250 kHz models) ? External parts : Coil, capacitor, and diode ? Output voltage : Selectable in 0.1 V steps between 1.5 V and 6.5 V (for VDD / VOUT separate types) Selectable in 0.1 V steps between 2.0 V and 6.5 V (for other than VDD / VOUT separate types) ? Output voltage accuracy : ±2.4% ? Oscillation frequency : 30 kHz, 50 kHz, and 250 kHz selectable ? Soft start function : 6 ms (50 kHz, typ.) ? Lead-free, Sn 100%, halogen-free ? Power supplies for portable equipment such as digital cameras, electronic notebooks, and PDAs ? Power supplies for audio equipment such as portable CD / MD players ? Constant voltage power supplies for cameras, VCRs, and communication devices ? Power supplies for microcomputers |
