S-75V08ANC 5V2 的参数 |
| 逻辑类型
Logic Type |
与门 AND Gate |
| 电路数
Number of Circuits |
1 |
| 输入数
Number of Inputs |
2 |
| 电源电压Vcc
Voltage - Supply |
2.0V~5.5V |
| 静态电流Iq
Current - Quiescent (Max) |
1uA |
| 输出高，低电平电流
Current - Output High, Low |
-8mA，8mA |
| 低逻辑电平
Logic Level - Low |
0.5V |
| 高逻辑电平
Logic Level - High |
1.5V |
| 传播延迟时间@Vcc，CL
Max Propagation Delay @ V, Max CL |
4.3ns @ 4.5V~5.5V，15pF |
| Description & Applications |
Features MINI LOGIC SERIES 2 INPUT AND GATE Wide power supply range: 2 V to 5.5 V Low current consumption: 1.0 μA max(at 5.5 V, 25°C) Typical propagation delay: tPD = 4.3 ns (at 5 V) High noise immunity: VNIH = VNIL = 28% VCC min Power down protection: All pins Lead-free |
| 描述与应用 |
特性 迷你逻辑系列2输入与门 宽电源电压范围：2 V至5.5 V 低消耗电流：1.0μA最大值（在5.5 V，25°C） 典型传播延迟：TPD =4.3纳秒（5 V） 高抗干扰性：VNIH= VNIL=28％VCC最小 掉电保护：所有引脚 无铅 |
| 技术文档PDF下载 |
在线阅读  |
|
|
|
|
|
相关型号列表 |
| 型号 |
标记/丝印/代码 |
厂家 |
批号 |
封装 |
数量 |
描述 |
详细资料 |
| S-75V00ANC |
5V1 |
SEIKO |
05+ |
SOT-353/SC-88A/SC70-5 |
9300 |
集成电路ICIntegrated Circuit（IC）-逻辑电路Logic circuit-逻辑门Gate |
查看 |
| S-75V02ANC |
5V3 |
SEIKO |
05+ |
SOT-353/SC-88A/SC70-5 |
7000 |
集成电路ICIntegrated Circuit（IC）-逻辑电路Logic circuit-逻辑门Gate |
查看 |
| S-75V04ANC |
5V5 |
SEIKO |
05+ |
SOT-353/SC-88A/SC70-5 |
8000 |
集成电路ICIntegrated Circuit（IC）-逻辑电路Logic circuit-逻辑门Gate |
查看 |
| S-75V08ANC |
5V2 |
SEIKO |
05+ |
SOT-353/SC-88A/SC70-5 |
4000 |
集成电路ICIntegrated Circuit（IC）-逻辑电路Logic circuit-逻辑门Gate |
查看 |
| S-75V04ANC |
5V5 |
SEIKO |
05+ |
SOT-353/SC-88A/SC70-5 |
0 |
集成电路ICIntegrated Circuit（IC）-逻辑电路Logic circuit-逻辑门Gate |
查看 |
| S-75V08ANC |
5V2 |
SEIKO |
05+ |
SOT-353/SC-88A/SC70-5 |
0 |
集成电路ICIntegrated Circuit（IC） |
查看 |
|
|
|
