SN74LVC2G157YEAR 的参数 |
| 类型
Type |
数据选择器/多路复用器 Multiplexer |
| 电路
Circuit |
1 x 2:1 |
| 独立电路
Independent Circuits |
1 |
| 输出高，低电流
Current - Output High, Low |
32mA，32mA |
| 单电源
Voltage Supply Source |
单电源 Single Supply |
| 电源电压
Voltage - Supply |
1.65 V ~ 5.5 V |
| Description & Applications |
This single 2-line to 1-line data selector/multiplexer is designed for 1.65-V to 5.5-V VCC operation.The SN74LVC2G157 features a common strobe (G) input. When the strobe is high, Y is low and Y is high.When the strobe is low, a single bit is selected from one of two sources and is routed to the outputs. The device provides true and complementary data.NanoFree? package technology is a major breakthrough in IC packaging concepts, using the die as the package.This device is fully specified for partial-power-down applications using Ioff. The Ioff circuitry disables the outputs,preventing damaging current backflow through the device when it is powered down. Available in the Texas Instruments NanoFree? Packages Supports 5-V VCC Operation Inputs Accept Voltages to 5.5 V Max tpd of 6 ns at 3.3 V Low Power Consumption, 10-μA Max ICC ±24-mA Output Drive at 3.3 V Ioff Supports Partial-Power-Down Mode Operation Latch-Up Performance Exceeds 100 mA Per JESD 78, Class II |
| 描述与应用 |
这个单2线1线数据选择器/多路复用器器设计用于1.65-V到5.5 V的VCC操作。SN74LVC2G157拥有一个共同的选通信号（G）输入。当选通信号高，Y是低和Y是高。当选通信号为低电平时，从两个来源之一选择一个单个位，被路由到输出??。该器件提供真正的和互补的数据。NanoFreeTM包装技术是IC包装概念的重大突破，使用冲模作为封装。这个装置是完全指定的部分断电应用程序使用IOFF。当断电时，IOFF电路关闭输出，防止破坏回流电流通过设备。 德州仪器NanoFree?软件包 支持5-V VCC操作 接受输入电压到5.5 V 在3.3 V时，最大TPD为6 ns 低功耗，10μA最大ICC ±24 mA输出驱动，在3.3 V时 IOFF支持部分断电模式操作 闭锁性能超过100 mA每JESD 78，II类 |
