P3100SBRP P31B 的参数 |
| 击穿电压VBO
Breakover voltage |
|
| 断态重复峰值电压VDRM
Repetitive peak off-state voltage |
275V |
| 峰值通态电压VTM
On-state voltage |
4V |
| 峰值脉冲电流(8 x 20us)
Current - Peak Pulse (8 x 20μs) |
150A |
| 峰值脉冲电流(10 x 1000us)
Current - Peak Pulse (10 x 1000μs) |
45A |
| 保持电流IH
Holding current |
150mA |
| Description & Applications |
DO-214AA SIDACtor solid state protection devices protect telecommunications equipment such as modems, line cards, fax machines, and other CPE. SIDACtor devices are used to enable equipment to meet various regulatory requirements including GR 1089, ITU K.20, K.21 and K.45, IEC 60950, UL 60950, and TIA/EIA-IS-968 |
| 描述与应用 |
固态保护设备可以保护电信设备 如调制解调器，线卡，传真机，以及其他CPE。 SIDACtor装置用于使能设备，以满足不同的监管要求 包括GR 1089 ITU K.20，K.21和K.45，IEC60950，UL60950，TIA/EIA-IS-968的 |
| 技术文档PDF下载 |
在线阅读  |
|
|
|
|
|
相关型号列表 |
| 型号 |
标记/丝印/代码 |
厂家 |
批号 |
封装 |
数量 |
描述 |
详细资料 |
| DSSA-P3100SBRP |
P31B |
MITSUBISHI |
05+ |
SMB/DO-214AA |
2240 |
可控硅/晶闸管Triac/Thyristor,SCR-浪涌吸收器Thyristor Surge Protection Devices |
查看 |
| P3100SBLRP |
P31B |
sidactor |
06+ |
SMB/DO-214AA |
80 |
可控硅/晶闸管Triac/Thyristor,SCR-浪涌吸收器Thyristor Surge Protection Devices |
查看 |
| P3100SBRP |
P31B |
sidactor |
05+ |
SMB/DO-214AA |
0 |
可控硅/晶闸管Triac/Thyristor,SCR-浪涌吸收器Thyristor Surge Protection Devices |
查看 |
| P3100SBRP |
P31B |
LITTELFUSE |
05+PB400 |
SMB/DO-214AA |
26000 |
可控硅/晶闸管Triac/Thyristor,SCR-浪涌吸收器Thyristor Surge Protection Devices |
查看 |
| P3100SCRP |
P31C |
sidactor |
05+ |
SMB/DO-214AA |
1590 |
可控硅/晶闸管Triac/Thyristor,SCR-浪涌吸收器Thyristor Surge Protection Devices |
查看 |
| P3100SDRP |
P31D |
sidactor |
05+ |
SMB/DO-214AA |
2500 |
可控硅/晶闸管Triac/Thyristor,SCR-浪涌吸收器Thyristor Surge Protection Devices |
查看 |
| P3100SARP |
P31A |
sidactor |
05+ |
SMC/DO-214AB |
4500 |
二极管Diodes-其它Other |
查看 |
|
|
|
