NLFC201614T-100K 的参数 |
| 电感值
Inductance |
10UH |
| 误差
Tolerance |
±10% |
| 额定电流
Current Rating |
120mA |
| 饱和电流
Current - Saturation |
|
| 不同频率时的Q值
Q @ Frequency |
10 @ 2.52MHz |
| 自振谐频率SRF
Frequency - Self Resonant |
32MHz |
| DC电阻DCR
DC Resistance (DCR) |
0.7Ω/Ohm |
| 屏蔽
Shielding |
屏蔽 Shielded |
| Description & Applications |
NLFC Series NLFC2016 FEATURES ? The product has good heat durability that withstands lead-free compatible reflow soldering conditions. ? Lead-free material is used for the plating on the terminal. ? The NLFC series features magnetic shielding and is recom-mended for power supply line applications. ? This product conforms to the standards that are slated to be introduced under the RoHS Directive. |
| 描述与应用 |
NLFC系列NLFC2016 特点 该产品具有良好的耐热性，可承受无铅兼容回流焊条件。 ?无铅材料可用于终端上的电镀。 ?NLFC系列具有磁屏蔽，建议用于电源线应用。 ?本产品符合预计将推出根据RoHS指令的标准。 |
