MLG1608B3N9ST000 的参数 |
| 电感值
Inductance |
3.9nH |
| 误差
Tolerance |
±0.3nH |
| 额定电流
Current Rating |
600mA |
| 饱和电流
Current - Saturation |
|
| 不同频率时的Q值
Q @ Frequency |
10 @ 100MHz |
| 自振谐频率SRF
Frequency - Self Resonant |
6.0GHz |
| DC电阻DCR
DC Resistance (DCR) |
0.14Ω/Ohm |
| 屏蔽
Shielding |
无屏蔽 Unshielded |
| Description & Applications |
MLG Series MLG1608 FEATURES ? Inductance values are supported from 1 to 1000nH. ? Advanced monolithic structure is formed using a multilayering and sintering process with ceramic and conductive materials for high-frequency. ? The products contain no lead and also support lead-free soldering. ? It is a product conforming to RoHS directive. |
| 描述与应用 |
MLG系列MLG1608 特点 ?电感值支持从1到1000nH。 ?产品中含有不含铅，也支持无铅焊接。 |
