EMIF02-SPK01F1 的参数 |
| 类型
Type |
低通 Low Pass |
| 技术
Technology |
RC |
| 通道数
Number of Channels |
2 |
| 中心/截止频率
Center / Cutoff Frequency |
|
| 衰减值
Attenuation Value |
|
| 电阻 - 通道 (Ω)
Resistance - Channel (Ohms) |
|
| 电流
Current |
|
| 数值
Values |
|
| ESD 保护
ESD Protection |
是 Yes |
| Description & Applications |
AIN PRODUCT CHARACTERISTICS: Where EMI filtering in ESD sensitive equipment is required : Mobile phones and communication systems Computers, printers and MCU Boards DESCRIPTION The EMIF02-SPK01 is a highly integrated device designed to suppress EMI/RFI noise in all systems subjected to electromagnetic interferences. The EMIF02 Flip-Chip packaging means the package size is equal to the die size. This filter includes an ESD protection circuitry which prevents damage to the application when subjected to ESD surges up 15 kV. BENEFITS EMI symmetrical (I/O) low-pass filter High efficiency in EMI filtering Very low PCB space consuming: 1.07 mm x 1.47 mm Very thin package: 0.65 mm High efficiency in ESD suppression High reliability offered by monolithic integration High reducing of parasitic elements through integration & wafer level packaging |
