ECH8613 FF 的参数 |
最大源漏极电压Vds
Drain-Source Voltage |
-12V |
最大栅源极电压Vgs(±)
Gate-Source Voltage |
10V |
最大漏极电流Id
Drain Current |
-5A |
源漏极导通电阻Rds
Drain-Source On-State Resistance |
60m?@ VGS = -2.5V, ID = -0.5A |
开启电压Vgs(th)
Gate-Source Threshold Voltage |
-0.4~-1.4V |
耗散功率Pd
Power Dissipation |
1.3W |
Description & Applications |
P-Channel Silicon MOSFET Ultrahigh-Speed Switching Applications Features ? Low ON-resistance. ? High-speed switching. ? 2.5V drive. |
描述与应用 |
P-沟道硅MOSFET 超高速开关应用 特点 ?低导通电阻。 ?高速开关。 ?2.5V驱动。 |
