EC4304C V 的参数 |
| 最大源漏极电压Vds
Drain-Source Voltage |
-30V |
| 最大栅源极电压Vgs(±)
Gate-Source Voltage |
10V |
| 最大漏极电流Id
Drain Current |
-0.25A |
| 源漏极导通电阻Rds
Drain-Source On-State
Resistance |
1.5Ω @-120mA,-4V |
| 开启电压Vgs（th）
Gate-Source Threshold Voltage |
-0.4--1.4V |
| 耗散功率Pd
Power Dissipation |
150mW/0.15W |
| Description & Applications |
? Low ON-resistance. ? High-speed switching. ? 2.5V drive. ? High resistance to damage from ESD (typ 300V) [with a protection diode connected between the gate and source]. |
| 描述与应用 |
?低导通电阻。 ?高速开关。 ?2.5V驱动。 ?高抗ESD损害（典型值300V）保护二极管之间连接的栅极和源] |
