| Description & Applications |
64×16bits serial EEPROM The BR93LC46-W series are CMOS serial input / output-type memory circuits (EEPROMs) that can be programmed electrically. Each is configured of 64 words × 16 bits (1,024 bits), and each word can be accessed individually and data read from it and written to it. Operation control is performed using five types of commands. The commands, addresses, and data are input through the DI pin under the control of the CS and SK pins. In a write operation, the internal status signal (READY or BUSY) can be output from the DO pin. Applications VCRs, TVs, printers, car stereos, cordless telephones, short wave radios, programmable DIP switches, and other battery-powered equipment requiring low voltage and low current Features 1) 64 words × 16 bits EEPROM 2) Operating voltage range When reading : 2.0 to 5.5V When writing : 2.7 to 5.5V3) Low current consumption Operating (at 5V) : 3mA (Max.) Standby (at 5V) : 5μA (Max.) 4) Address can be incremented automatically during read operations. 5) Auto erase and auto complete functions can be use during write operations. 6) A write instruction inhibit function allows : - write protection when power supply voltage is low. - write disable state at power up. - writing using command codes. 7) Compact packages 8) Display of READY / BUSY status 9) TTL-compatible input / output 10) Rewriting possible up to 100,000 times 11) Data can be stored for ten years without corruption. |
