型号： |
74LVC1G32ADY |
| 标记/丝印/代码/打字： |
LG |
| 厂家： |
IDT |
| 封装： |
SOT-353/PSOP5 |
| 批号： |
05+ |
| 库存数量： |
1000 |
| 所属分类： |
集成电路ICIntegrated Circuit（IC）
逻辑电路Logic circuit
逻辑门Gate |
| 技术文档PDF： |
在线阅读  |
| |
|
| 在线购买 |
|
|
|
|
74LVC1G32ADY LG 的参数 |
| 逻辑类型
Logic Type |
或门 OR Gate |
| 电路数
Number of Circuits |
1 |
| 输入数
Number of Inputs |
2 |
| 电源电压Vcc
Voltage - Supply |
1.65V~3.6V |
| 静态电流Iq
Current - Quiescent (Max) |
500uA |
| 输出高，低电平电流
Current - Output High, Low |
-24mA，24mA |
| 低逻辑电平
Logic Level - Low |
0.7V~0.8V |
| 高逻辑电平
Logic Level - High |
1.7V~2V |
| 传播延迟时间@Vcc，CL
Max Propagation Delay @ V, Max CL |
|
| Description & Applications |
SINGLE 2-INPUT POSITIVE-OR GATE；FEATURES 0.5 MICRON CMOS Technology ESD > 2000V per MIL-STD-883, Method 3015; > 200V using machine model (C = 200pF, R = 0) 0.65mm pitch PSOP package Extended commercial range of – 40°C to +85°C VCC = 3.3V ±0.3V, Normal Range VCC = 1.65V to 3.6V, Extended Range VCC = 2.5V ±0.2V CMOS power levels (0.4μ W typ. static) Rail-to-Rail output swing for increased noise margin All inputs, outputs and I/O are 5 Volt tolerant Supports hot insertion |
| 描述与应用 |
单双输入正或门；特性 0.5微米CMOS技术 ESD> 2000V每MIL-STD-883方法3015; > 200V使用机型（C =200pF的，R = 0） 0.65mm间距PSOP包装 扩展商业范围 - 40°C至+85°C VCC=3.3V±0.3V，正常范围 VCC= 1.65V至3.6V，扩展范围 VCC=2.5V±0.2V CMOS功率水平（0.4μW TYP静） 轨到轨输出摆幅噪声裕量增加 所有输入，输出和I / O是5伏宽容 支持热插入 |
