2SC3265-O EO 的参数 |
| 集电极-基极反向击穿电压V(BR)CBO
Collector-Base Voltage(VCBO) |
35V |
| 集电极-发射极反向击穿电压V(BR)CEO
Collector-Emitter Voltage(VCEO) |
25V |
| 集电极连续输出电流IC
Collector Current(IC) |
800mA/0.8A |
| 截止频率fT
Transtion Frequency(fT) |
120MHz |
| 直流电流增益hFE
DC Current Gain(hFE) |
100~200 |
| 管压降VCE（sat）
Collector-Emitter Saturation Voltage |
400mV/0.4V |
| 耗散功率Pc
Power Dissipation |
200mW/0.2W |
| Description & Applications |
NPN Epitaxial Silicon Transistors Applications Low frequency power amplifer applications Power switching applications Features Higjh DC current gain Low saturation voltage Complementary to 2SA1298 |
| 描述与应用 |
NPN外延硅晶体管 应用 低频电源放大器应用 电源开关应用 特点 Higjh直流电流增益 低饱和电压 互补2SA1298 |
