1SS123
 型号:  1SS123
 标记/丝印/代码/打字:  A7
 厂家:  NEC
 封装:  SOT-23/SC-59
 批号:  05+
 库存数量:  0
 所属分类:  二极管Diodes
  开关二极管Switching Diodes
    双管串联1 PAir Series Connection
 技术文档PDF:  在线阅读

 在线购买

1SS123 A7 的参数

反向电压Vr Reverse Voltage 70V
平均整流电流Io Average Rectified Current 100mA/0.1A
最大正向压降VF Forward Voltage(Vf) 1.3V
反向恢复时间Trr Reverse Recovery Time 9.0NS
最大耗散功率Pd Power Dissipation
Description & Applications Silicon switching diodes. The 1SS123 consists of two high-speed switching diodes connected in series . low cApAcitAnce ?high speed switching .wide ApplicAtion including switching,limitter,clipper ,double diode configurAtion Assures economicAl use
描述与应用 硅开关二极管 1SS123由两个高速开关二极管串联连接, 低电容, 高速交换, 广泛的应用,包括开关,限幅器,剪 双二极管配置,保证节约使用.
技术文档PDF下载 在线阅读



 相关型号列表

型号 标记/丝印/代码 厂家 批号 封装 数量 描述 详细资料
1SS123 A7 NEC 05+ SOT-23/SC-59 0 二极管Diodes-开关二极管Switching Diodes-双管串联1 PAir Series Connection 查看
1SS123 A7 NEC 05+ SOT-23/SC-59 0 二极管Diodes-开关二极管Switching Diodes-双管串联1 PAir Series Connection 查看
1SS153 A9 NEC 05+ SOT-23/SC-59 18000 二极管Diodes-开关二极管Switching Diodes 查看
1SS153 A9 NEC 05+ SOT-23/SC-59 24900 二极管Diodes-开关二极管Switching Diodes 查看
1SS154 BA TOSHIBA 05+ SOT-23/SC-59 2330 二极管Diodes-肖特基势垒二极管SBDSchottky Barrier Diodes-单管Single 查看
1SS154 BA TOSHIBA 05+ SOT-23/SC-59 0 二极管Diodes-肖特基势垒二极管SBDSchottky Barrier Diodes-单管Single 查看
1ss181 A3 TOSHIBA 05+ SOT-23/SC-59 69000 二极管Diodes-开关二极管Switching Diodes-双管共阳极1 PAir Common Anode 查看
1SS181 A3 TOSHIBA 12+ROHS SOT-23/SC-59 46800 二极管Diodes-开关二极管Switching Diodes-双管共阳极1 PAir Common Anode 查看
1SS184 B3 TOSHIBA 11+ SOT-23/SC-59 0 二极管Diodes-开关二极管Switching Diodes-双管共阴极1 PAir Common CAthode 查看
1SS184 B3 TOSHIBA 05+ SOT-23/SC-59 1000 二极管Diodes-开关二极管Switching Diodes-双管共阴极1 PAir Common CAthode 查看
1SS187 D3 TOSHIBA 12+rohs SOT-23/SC-59 0 二极管Diodes-开关二极管Switching Diodes-单管Single 查看
1SS187 D3 TOSHIBA 05+ SOT-23/SC-59 500 二极管Diodes-开关二极管Switching Diodes-单管Single 查看
1SS190 E3 TOSHIBA 12+ROHS SOT-23/SC-59 0 二极管Diodes-开关二极管Switching Diodes-单管Single 查看
1SS190 E3 TOSHIBA 07+ROHS SOT-23/SC-59 50 二极管Diodes-开关二极管Switching Diodes-单管Single 查看
1SS193 F3 TOSHIBA 11+ROHS SOT-23/SC-59 18950 二极管Diodes-开关二极管Switching Diodes-单管Single 查看
1SS193 F3 TOSHIBA 05+ SOT-23/SC-59 12000 二极管Diodes-开关二极管Switching Diodes-单管Single 查看
1SS196 G3 TOSHIBA 05+ SOT-23/SC-59 33000 二极管Diodes-开关二极管Switching Diodes-单管Single 查看
1SS196 G3 TOSHIBA 05+ SOT-23/SC-59 34500 二极管Diodes-开关二极管Switching Diodes-单管Single 查看
1SS181 A3 TOSHIBA 05+ SOT-23/SC-59 0 二极管Diodes-开关二极管Switching Diodes-双管共阳极1 PAir Common Anode 查看
1SS184S B3 TOSHIBA 12+ROHS SOT-23/SC-59 600000 二极管Diodes-开关二极管Switching Diodes-双管共阴极1 PAir Common CAthode 查看
